GAO Tek 2.4 GHz 14 dBi Outdoor Directional Antenna

This direction antenna operates at 2.4 GHz and has a 14 dBi signal gain.

304020tek

Description

Overview

This direction antenna operates at 2.4 GHz and has a 14 dBi signal gain. It is designed to strengthen the signal power, increase the wireless range, reduce dead spots, and provide reliability at high data rates. The antenna uses an N-Type female connector guaranteeing wide compatibility with most wireless equipment such as access points, routers, bridges and network adapters. It has a weather proof design, which allows it to perform normally in various demanding outdoor solutions. In addition, the antenna does not require configuration or installation of software.

Key Features

  • Directional operation
  • 14 dBi signal gain
  • Compliant with 802.11b/g and 2.4 GHz wireless application
  • N Female connector which works with most access points or wireless routers
  • 100 cm low loss CFD-200 cable for flexible deployment
  • Easy installation mounting kit

Technical Specifications

Frequency 2.4 GHz to 2.5 GHz
Impendence 50 Ohms
Gain 14 dBi
Type Directional
VSWR (Max.) 1.92 : 1
HPBW/H 30 °
HPBW/V 30 °
Polarization Linear; Vertical
Connector Type N Female (Jack)
Extended Cable/Length CFD-200; 100 cm
Mounting Wall Mount/ Desktop
Application Outdoor
Approximate Range at 1/11/54 mbps 1.77 km/ 1 km/ 140 m
Dimensions 240 mm × 240 mm × 40 mm
Operating Temperature -20 °C to 65 °C
Storage Temperature -30 °C to 75 °C
Operating Humidity 10% to 90%, non-condensing
Storage Humidity 5% to 90%, non-condensing
Standards RoHS, WEEE
Optional Accessory 6 m Low-Loss Antenna Extension Cable
12 m Low-Loss Antenna Extension Cable
Surge Protector
Pigtail Cable
